I have an Unifi AP which is capable of making multiple wlans. The AP is connected to a tplink smartswitch from which it gets internet access and sees everything in the network. The switch is connected to the gateway server, the AP gets it's ip from there. I'd like to make 2 wlans, one of them has to have access to the current network and the other one would be a 'guest' wlan which would have only internet access and would not see the internal network with all the other servers on it.
Dec 07, 2015 Reset TP Link TL-SG3424 when you can't access the web console. By GarethShaw. On Jun 18, 2013 at 22:11 UTC. General Networking. Next: PFsense PPPOE Non. Connect it to the console port and get the info I needed via Hyper Terminal. For TL-SG2424 V2 To Use Third Party Firmware In TP-Link Products Some official firmware of TP-Link products can be replaced by the third party firmware such as DD-WRT.
T1600g 28ts Tl Sg2424
Is it be possible to have one of the guest wlan in a vlan so it wouldn't see the internal network (only internet access), and the leave the other one as it is without setting any vlan for it?Thanks in advance! Just create a second VLAN for your guest and make sure the uplink ports have the VLAN tagged all the way to your server that is performing the routing/NAT. So tag the new VLAN on the edge port the server is connecting to as well.You have to make sure that your server NIC does understand VLAN tags. If it does not, you will need to get one that does or install a second NIC that will be dealing with the additional VLAN/Subnet.On the edge port where your access point is connecting, make sure that the guest VLAN is tagged and your main VLAN is either tagged or untagged, depending on the configuration on the access point.When creating your WLAN, make sure that you specify which VLAN each WLAN has to use.So for Main SSID you can say VLAN1, and your Guest SSID, VLAN2.
Tl Sg2424 How To Connector
This will make sure that the connection is placed on the correct VLAN once a client connects to the AP.For the guest subnet, you need to assign a range of IP addresses, with your server being the gateway.You will also need to deal with DHCP on this VLAN so you need some kind of DHCP relay-agent on the server but I am not 100% sure how this would be configured on your setup, not knowing all the details. Normally you will confiure this on your switch that has the vlan interface configured, which in this case I believe would be your server. If this server is also a DHCP server, then I think as long as the new DHCP scope has been created, you should be all good.Get pfsense to do the routing from your guest VLAN to your WAN interface but do not allow it route to the main VLAN and obviously configure NAT to allow this new subnet to get out to the Internet.Hope this helps you on your quest.SleepyMan.
